BROADFOIL FSK Facing Aluminum Foil

BROADFOIL FSK facing aluminum foil insulation are usually used as facing for glass wool insulation, rockwool, rubber foam etc. Also used under roof decking, under attic rafters, over existing attic thermal insulation, in floors, walls and crawl spaces, and in industrial and commercial buildings to block radiant heat coming into house through the roof during the summer and retain indoor heat generated during in winter.

Features of BROADFOIL FSK Facing Aluminum Foil

1.Smooth surface & Good Reflective on the aluminum foil.

2.Good stretching resistance in length and breadth

3.Moisture barrier,water-proof, fire-retarding and anti-corrosion

4.Heat Insulation Facing with high tensile strength and bursting strength

5.Keeps warm in winter and cool in summer

6.Environmentally-friendly thermal insulation material

Specifications of BROADFOIL FSK Facing Aluminum Foil

Item	Specfications
Model	BR-FSK-C
Appearance	Side as the silver, while on the surface of the kraft paper laminating, reflecting slightly above the rate
Structure	(7 micron) foil/adhesive/tri-way fiberglass srim/kraft/PE
width	1.0-1.3m
Roll length	50-2000m

Technical Data of BROADFOIL FSK Facing Aluminum Foil

Physical Properties	Test  Method	Values (English)	Values(Metric)
Basis Weight	Scale	25.5lbs/1000 ft2	125g/m2
Tensile Strength	GB/T12914-1991	22.5lbs/inch(MD)	3.79 kn/m(MD)
		13.9lbs/inch(XD)	2.31 kn/m(XD)
Bursting Strength	GB/T454-2002	36 lbs/psi	248 kpa
Water-resistant	23 °C 24h	No phenomenon of layered	No phenomenon of layered
Low-temperature resistant	-40 °C 1h	No phenomenon of layered	No phenomenon of layered
High temperature resistant	116 °C 4h	No leakage phenomenon	No leakage phenomenon
Thickness	Micrometer	0.0058 inch	150 micron

Packing & Delivery of BROADFOIL FSK Facing Aluminum Foil

Packing:  In Kraft paper Packing or according to client's requirement.
Delivery time: Our powerful production capacity will ensure timely delivery time, normal 5-7 days is enough!
