BROADFOIL FSK facing aluminum foil insulation are usually used as facing for glass wool insulation, rockwool, rubber foam etc. Also used under roof decking, under attic rafters, over existing attic thermal insulation, in floors, walls and crawl spaces, and in industrial and commercial buildings to block radiant heat coming into house through the roof during the summer and retain indoor heat generated during in winter.
1.Smooth surface & Good Reflective on the aluminum foil.
2.Good stretching resistance in length and breadth
3.Moisture barrier,water-proof, fire-retarding and anti-corrosion
4.Heat Insulation Facing with high tensile strength and bursting strength
5.Keeps warm in winter and cool in summer
6.Environmentally-friendly thermal insulation material
Item |
Specfications |
Model |
BR-FSK-C |
Appearance |
Side as the silver, while on the surface of the kraft paper laminating, reflecting slightly above the rate |
Structure |
(7 micron) foil/adhesive/tri-way fiberglass srim/kraft/PE |
width |
1.0-1.3m |
Roll length |
50-2000m |
Physical Properties |
Test Method |
Values (English) |
Values(Metric) |
Basis Weight |
Scale |
25.5lbs/1000 ft2 |
125g/m2 |
Tensile Strength |
GB/T12914-1991 |
22.5lbs/inch(MD) |
3.79 kn/m(MD) |
|
|
13.9lbs/inch(XD) |
2.31 kn/m(XD) |
Bursting Strength |
GB/T454-2002 |
36 lbs/psi |
248 kpa |
Water-resistant |
23 °C 24h |
No phenomenon of layered |
No phenomenon of layered |
Low-temperature resistant |
-40 °C 1h |
No phenomenon of layered |
No phenomenon of layered |
High temperature |
116 °C 4h |
No leakage phenomenon |
No leakage phenomenon |
Thickness |
Micrometer |
0.0058 inch |
150 micron |
Packing: In Kraft paper Packing or according to client's requirement.
Delivery time: Our powerful production capacity will ensure timely delivery time,
normal 5-7 days is enough!
