BROADFOIL Fiberglass Cloth Aluminum Foil

BROADFOIL Aluminum foil laminated fiberglass cloth usually used for housetop or floor heat insulation or auto engine or construction heat insulation.

Wide Supply Scope

Spec	Supply Scope
Roll Length	no less than 50m (Special seizes available upon request)
Roll width	30mm-1200mm
Core I.D.	3"(76mm+/-1)

Features of BROADFOIL Fiberglass Cloth Aluminum Foil

1. Fire resistant , moisture resistance.

2. Low weight, high strength

3. High rigidity

4. Good corrosion characteristics

5. Resistant to a variety of chemicals.

6. Good thermal and soundproof qualities

Applications of BROADFOIL Fiberglass Cloth Aluminum Foil

1.it can be used to Wrap the air-conditioning outlet.
2.Aluminum foil laminated fiberglass cloth could be cut to wrap around the glass wool in different sizes for inserting between the main body and the inner body of the subway wagons, for insulating against temperature and sound.

Technical Data of BROADFOIL Fiberglass Cloth Aluminum Foil

Product Structure		Description
Alu.Foil		7µm
Adhesive		PE
Fiberglass Fabric		95g/m2
Physical Property	Value		Test Method
Basic Weight	155 g/m²		Scale
Tensile Strength MD	376.9 N/25mm		GB/T 7689.5-2001
Tensile Strength CD	226.4 N/25mm		GB/T 7689.5-2001
Burst Strength	383.4N		GB/T 454-2002
Reflectivity	95%		-
Temperature Resistance	-26°C to 66°C not delaminating		-
Water Vapor Permeability	-		-

Packing & Delivery of BROADFOIL Fiberglass Cloth Aluminum Foil

Packing:  In Kraft paper Packing or according to client's requirement.
Delivery time: Our powerful production capacity will ensure timely delivery time, normal 5-7 days is enough!
