BROAD Glass Wool Pipe Insulation

BROAD Glass wool pipe is specially used the heat insulation of in all sorts of pipes (such as refrigeration, hot water and steam) system, working well under the environment with a temperature less than 454°C, exposing or covered. With excellent quality, competitive price, prompt delivery, we have exported our glass wool pipe to over 80 countries.

Benefits of BROAD Glass Wool Pipe Insulation

No added formaldehyde.

Low product emissions.

Lower embodied energy.

Lower environmental impact.

Softer feel

Applications of BROAD Glass Wool Pipe Insulation

Heat preservation for steel structure building.

Heat insulation for wall and roof of house to save energy.

For indoor partition wall, Train compartment.

For cool-making and high buildings required to be fireproof, heat resistant and sound insulation.

Package of BROAD Glass Wool Pipe Insulation

Our standard package: Vacuum compressed packing in plastic bag and plastic woven bag.
However, due to excellent rebound property, when reach the destination our glass wool will rebound almost to the original level in 24 hours after been unpacked

Technical Data Sheet of BROAD Glass Wool Pipe Insulation

Number	Item	Unit	National Standard	Company Product	Remark
1	Density	kg/m3		10-48	GB483.3-85
2	Avearage Fiber diameter	μm	≤8.0	5.5	GB5480.4-85
3	Hygroscopicity	%	≥98	98.2	GB10299-88
4	Thermal Conductivity	w/m.k	≤0.042	0.033	GB10294-88
5	Noncombustibility	0	Noncombustible	Noncombustible (A)	GB5464-85
6	Sound Absorption Coefficient	0	0	1.03 product reverberation method 24kg/m3 2000HZ	GBJ47-83
7	Highest usage Temperature	°C	≤480	480	GB11835-89
