BROAD glass wool blanket is made of pure non-colour glass flat board as raw material, which comes directly from flat glass factories, we do not use cycled glass wool. We totally have 8 producing lines for Glass wool with capacity over 1,800,000 tons per year.
Our products have passed CE, ISO, A1, BV and AS/NZ certificates and we have strict quality management system. With excellent quality, competitive price, prompt delivery, we have exported our glass wool blanket to over 80 countries.
Spec |
Supply Scope |
Length |
5-30m |
Width |
0.4m-1.2m |
Thickness |
25-200mm |
Density |
10-50kg/m3 |
Facing(optional) |
Aluminum foil, Kraft, PVC |
1. Long and thin glass fiber is good for thermal insulation and sound absorbing.
2. Excellent rebound degree can be up to 99.2%.when unpacked in 24 hours.
3. Grade A1 incombustible materials.
4. Low moisture absorption; stable physical properties.
5. Easy for construction; cutting at will.
Model |
Density (Kg/m3) |
Thickness |
Width |
Standard Length(m) |
Loading qty/40HQ (rolls) |
BR-10T50 |
10 |
50 |
1,200 |
25 |
500 |
BR-10T75 |
75 |
1,200 |
25 |
330 |
|
BR-10T100 |
100 |
1,200 |
15 |
450 |
|
BR-12T40 |
12 |
40 |
1,200 |
25 |
600 |
BR-12T50 |
50 |
1,200 |
20 |
600 |
|
BR-12T75 |
75 |
1,200 |
25 |
260 |
|
BR-12T100 |
100 |
1,200 |
20 |
224 |
|
BR-16T25 |
16 |
25 |
1,200 |
30 |
520 |
BR-16T50 |
50 |
1,200 |
25 |
280 |
|
BR-16T75 |
75 |
1,200 |
20 |
224 |
|
BR-16T100 |
100 |
1,200 |
15 |
224 |
|
BR-24T25 |
24 |
25 |
1,200 |
25 |
410 |
BR-24T50 |
50 |
1,200 |
20 |
260 |
|
BR-24T75 |
75 |
1,200 |
15 |
224 |
|
BR-24T100 |
100 |
1,200 |
10 |
260 |
|
BR-32T25 |
32 |
25 |
1,200 |
25 |
280 |
BR-32T50 |
50 |
1,200 |
15 |
260 |
|
BR-32T75 |
75 |
1,200 |
10 |
260 |
|
BR-32T100 |
100 |
1,200 |
8 |
224 |
|
BR-50T25 |
50 |
25 |
1,200 |
15 |
330 |
BR-50T50 |
50 |
1,200 |
10 |
224 |
|
BR-50T75 |
75 |
1,200 |
7 |
224 |
|
BR-50T100 |
100 |
1,200 |
6 |
200 |
Packing: PP and PE Vacuum Packing. Different colors and OEM service are available.
Delivery time: our powerful production capacity ensures shortest delivery time, normally 5-7 days is
enough.
Number |
Item |
Unit |
National Standard |
Test Data |
Remark |
1 |
Density |
kg/m3 |
|
10-50 |
GB483.3-85 |
2 |
Average Fiber diameter |
μm |
≤8.0 |
5.5 |
GB5480.4-85 |
3 |
Hygroscopic |
% |
≥98 |
98.2 |
GB10299-88 |
4 |
Thermal Conductivity |
w/m.k |
≤0.042 |
0.033 |
GB10294-88 |
5 |
Non-combustibility |
|
Noncombustible |
Noncombustible (A) |
GB5464-85 |
6 |
Sound Absorption Coefficient |
|
|
1.03 product reverberation method 24kg/m3 2000HZ |
GBJ47-83 |
7 |
Highest usage Temperature |
°C |
≤410 |
410 |
GB11835-89 |
